The lifts
One platform.
Three ways to finish it.
Classic, Pro, or Premium, the structure never varies: a double I-beam cantilever in 6061 aluminum, rated for a half-ton, built to live outdoors. You choose the motor, the beam, and how far the finish goes.
- Load capacity
- 1,000 lbs
- Rated maximum load, every series
- Basket interior
- 4' × 4'
- 54¼" × 54¼" outside, 42" inside walls
- Side height
- 46"
- Gate opening 35⅝" × 46¾"
- Travel speed
- ~14 ft/min
- Smooth, controlled vertical travel
- Standard travel
- Up to 17'
- Taller runs available, priced per foot
- Min. deck opening
- 56"
- So the basket gate can fully open
Side by side
Where the series part ways.
Shared bones, different builds. If you're between two, the Pro's sealed motor and standard brake settle most debates.
| Classic Series | Pro SeriesMOST CHOSEN | Premium Series | |
|---|---|---|---|
| Positioning | The essential lift | The one most homes choose | The finished statement |
| Motor | TEFC: totally enclosed, fan-cooled | TENV: totally enclosed, non-vented, maintenance-free | TENV: totally enclosed, non-vented, maintenance-free |
| Power | 120 V or 220 V single-phase (dedicated circuit) | Dedicated 220 V single-phase | Dedicated single-phase circuit, voltage confirmed at spec time |
| I-beam | 3" × 4" double I-beam | 3" × 5" double I-beam | 3" × 5" double I-beam |
| Safety brake | Mechanical safety brake available | Mechanical cam-and-wedge brake, standard | Mechanical cam-and-wedge brake, standard |
| Details | Details | Details |
Make it yours
Configured to the home, down to the color.
Every lift is built to order. These are the levers you can pull. We'll tell you which ones your installation needs.
Gates & doors
- Extra basket gates
- Deck gates
- Self-closing saloon gates
- Interlocked deck gates
- Accordion door (Premium)
Controls & access
- Call/send stations at each landing
- Extra wireless remotes
- Keyed power isolation switch
- Hurricane control kit
Safety systems
- Pan switch (under-basket obstruction stop)
- Pinch-point edge protection
- Gate & basket interlocks
- Mechanical safety brake
Structure & finish
- Custom basket sizes
- Travel beyond 17 feet
- Beach-front foot plates
- Aluminum roof
- Powder coating in 186 RAL colors
Next step
Put your stairs on light duty.
Book a free consultation: thirty minutes, straight answers, and a written quote for the exact lift your home needs.
