The essential lift
Classic Series.
The proven workhorse: the double I-beam cantilever, the aluminum basket, and the half-ton capacity that define a WC cargo lift, in their most straightforward form.
Get a quote for the Classic Series
Single-level decks · Shorter travel runs · Value-focused builds
TEFC motor
Totally enclosed, fan-cooled, rated for 100% duty cycle
Flexible power
Runs on 120 V or 220 V single-phase, by configuration
3" × 4" I-beam
Ideal for installations under 10 feet of travel
Specifications
The Classic Series, by the numbers.
- Motor
- TEFC: totally enclosed, fan-cooled
- Power
- 120 V or 220 V single-phase (dedicated circuit)
- I-beam
- 3" × 4" double I-beam
- Safety brake
- Mechanical safety brake available
- Load capacity
- 1,000 lbsRated maximum load, every series
- Basket interior
- 4' × 4'54¼" × 54¼" outside, 42" inside walls
- Side height
- 46"Gate opening 35⅝" × 46¾"
- Travel speed
- ~14 ft/minSmooth, controlled vertical travel
- Standard travel
- Up to 17'Taller runs available, priced per foot
- Min. deck opening
- 56"So the basket gate can fully open
Custom basket sizes, travel beyond 17 feet, and site-specific bracing are engineered per order. Every installation requires a dedicated circuit wired by a licensed electrician to NEC and local code.
